MUD GATE VALVES

The LEOPARD mud Gate Valves, with superior design features precision workmanship and a proven principle are engineered to meet the harsh drilling requirements in today’s oilfield.

The LEOPARD valves conforms to the standard flange dimensions and pressure rating of 5000 and 7500 PSl working pressure, and temperature service up to 400°F.

CONSTRUCTION

LEOPARD Valves conform to API flange dimensions in all pressure class ratings. The valves have rising stems that are driven by a double threaded hub for quick opening and closing with minimum turning effort. The permanently lubricated stems and stem screws are fully sealed assembly consisting of homogeneous and fabric backed rings for high and low pressure sealing.

The valve standard trim includes 316SS gates 316SS stems and Buna N seats,optional trims are available which include Ni Plated Carbon Steel, Monel, and Aluminum Bronze gates. Seats are offered in Viton and Hypalon and optional 303SS stem is available.

Specification

Size Range:  2” 3” 4” 4x5”

Design: Demco, Oteco

Working Pressure: 3000psi 5000 psi

Connection: Flanged, Screwed, Welded, Union
