Manual Tong
Manual Tong
Description
Torque
Weight
Part no.
Description
Torque
Weight
Part no.
HT 14
HT 55
Complete less lug jaws
----
99
200640
Complete with long lever, less lug jaws
----
400
200560
Lug jaw assembly 2-3/8” ~ 3-1/2”
10000
12
200645-1
Complete with short lever, less lug jaws
----
386
200560-1
Lug jaw assembly 3-1/2” ~ 5”
10000
15
200646-1
Lug jaw assembly 3-1/2” ~ 5”
35000
29
200083-1
Lug jaw assembly 4-3/4” ~ 6-1/4”
14000
24
200647-1
Lug jaw assembly 5” ~ 6-3/4”
55000
39
200084-1
Lug jaw assembly 5-3/4” ~ 7”
12000
31
200648-1
Lug jaw assembly 6-5/8” ~ 9”
55000
56
200085-1
HT 35
Lug jaw assembly 9” ~ 10-3/4”
40000
60
200086-1
Short lever 7-5/8” x 10-3/4” less lug jaws
----
----
200620-1
Lug jaw assembly 11-3/4”
30000
61
200087-1
Long lever 2-3/8” x 7” less lug jaws
----
242
200620-2
Lug jaw assembly 12”
30000
65
200088-1
Short lever 2-3/8” x 7” less lug jaws
----
238
200620-3
Lug jaw assembly 12-3/4” ~ 13”
30000
72
200089-1
Lug jaw assembly 2-3/8” ~ 3.668”
15000
25
200076-1
Lug jaw assembly 13-3/8”
30000
72
200090-1
Lug jaw assembly 2-7/8” ~ 4-1/4”
15000
29
200077-1
Lug jaw assembly 3-1/2” ~ 5-1/4”
25300
33
200078-1
Lug jaw assembly 5-1/4” ~ 7”
33500
45
200079-1
Hinge and lug jaw assembly 7” ~ 8-5/8”
25000
33
200080-2
Hinge and lug jaw assembly 9-5/8” ~ 10-3/4”
32000
76
200081-2
Ft.lbs
Lbs
Ft.lbs
Lbs
TECHNICAL SPECIFICATIONS
|
Description |
Torque |
Weight |
Part no. |
Description |
Torque |
Weight |
Part no. |
|
|
HT 65 |
HT 50* |
|||||||
|
Complete less lug jaws |
---- |
440 |
200540 |
Casing head assembly 13-3/8” ~ 14-1/2” |
25000 |
340 |
200580-1 |
|
|
Lug jaw assembly 3-1/2” ~ 8-1/4” |
65000 |
82 |
200546-1 |
Casing head assembly 14-1/2” ~ 16” |
25000 |
352 |
200580-2 |
|
|
Lug jaw assembly 8” ~ 11-1/4” |
65000 |
97 |
200547-1 |
Casing head assembly 16” ~ 17-1/2” |
25000 |
373 |
200580-3 |
|
|
Lug jaw assembly 11-3/4” ~ 14-3/8” |
40000 |
71 |
200548-1 |
Casing head assembly 17-1/2” ~ 19” |
25000 |
385 |
200580-4 |
|
|
Lug jaw assembly 16” ~ 17” |
40000 |
83 |
200549-1 |
Casing head assembly 19” ~ 20” |
25000 |
397 |
200580-5 |
|
|
Hinge jaw assembly 8” ~ 17” |
40000 |
56 |
200545-1 |
Casing head assembly 20” ~ 21-1/2” |
25000 |
418 |
200580-6 |
|
|
Casing head assembly 21-1/2” ~ 23” |
25000 |
430 |
200580-7 |
|||||
|
HT 100 |
Casing head assembly 24” ~ 25-1/2” |
25000 |
459 |
200580-8 |
||||
|
Complete less lug jaws |
---- |
533 |
200071 |
Casing head assembly 25-1/2” ~ 27” |
25000 |
490 |
200600-1 |
|
|
Lug jaw assembly 4” ~ 8-1/2” |
100000 |
135 |
200663-1 |
Casing head assembly 27” ~ 28-1/2” |
25000 |
499 |
200600-2 |
|
|
Lug jaw assembly 8-1/2” ~ 12” |
100000 |
102 |
200664 |
Casing head assembly 28-1/2” ~ 30” |
25000 |
531 |
200600-3 |
|
|
Lug jaw assembly 12” ~ 15” |
75000 |
140 |
200665 |
Casing head assembly 30” ~ 31-5/8” |
25000 |
542 |
200600-4 |
|
|
Lug jaw assembly 15-3/4” |
60000 |
162 |
200666 |
Casing head assembly 31-1/2” ~ 33” |
25000 |
572 |
200600-5 |
|
|
Lug jaw assembly 16” ~ 17” |
60000 |
135 |
200667 |
Casing head assembly 33” ~ 34-1/2” |
25000 |
612 |
200600-6 |
|
|
Hinge jaw assembly 8-1/2” ~ 17” |
60000 |
112 |
200662-1 |
Casing head assembly 34-1/2” ~ 36” |
25000 |
618 |
200600-7 |
|
NOTE
*HT 50 casing head assembly only, to be used with HT 55 tong and hanger.
PARTS LIST HT 50 CASING HEAD ASSEMBLIES
|
Range |
Casing head assy P/N |
Range |
Casing head assy P/N |
Range |
Casing head assy P/N |
|
|
13 3/8” to 14 1/2” |
200580-1 |
20” |
to 211/2” |
200580-6 |
281/2” to 30” |
200600-3 |
|
14 1/2” to 16” |
200580-2 |
211/2” |
to 23” |
200580-7 |
30” to 315/8” |
200600-4 |
|
16” to 17 1/2” |
200580-3 |
24” |
to 251/2” |
200580-8 |
311/2” to 33” |
200600-5 |
|
17 1/2” to 19” |
200580-4 |
251/2” |
to 27” |
200600-1 |
33” to 341/2” |
200600-6 |
|
19” to 20” |
20580-5 |
27” |
to 271/2” |
200600-2 |
341/2” to 36” |
200600-7 |
